Engage RF Insert, 50 GHz SSMP Fixture Side

Fixture side of resource pair. Requires RIK0316A SSMP Connector. Frequency to 26 GHz to DIB or 50 GHz to Top Hat DIB. Power up to CW 100 Watts.

Part Number: RIK0323A

Estimated Restocking Time: 4-6 weeks

$1,450
NOTE: Thread-locking fluid (RIK0204A) should be applied to screws.

Frequency to 26 GHz to DIB or 50 GHz to Top Hat DIB. Power up to CW 100 Watts.

Bottom and TOP shown installed.

Board Bottom (RIK0316A)
Fixture Top (RIK0323A)



SSMP PCB Application Note_v5.pdfSSMP PCB Application Note_v5.pdf
