Engage RF Insert, 50 GHz SSMP Fixture (Side B)

Fixture side of resource pair. Requires RIK0316A SSMP Connector. Frequency to 26 GHz to DIB or 50 GHz to Top Hat DIB. Power up to CW 100 Watts.

Part Number: RIK0323A

Estimated Restocking Time: 4-6 weeks

$1,454
NOTE: Thread-locking fluid (RIK0204A) should be applied to screws.

Frequency to 26 GHz to DIB or 50 GHz to Top Hat DIB. Power up to CW 100 Watts.

Bottom and TOP shown installed.

Board Bottom (RIK0316A)
Fixture Top (RIK0323A)



SSMP PCB Application Note_v5.pdf

For Calibration buy this




©2022 Roos Instruments, Inc. All rights reserved.

Reference URL:
http://roos.com/docs/JCON-9DDM5C?Open

Related Documents:

User account required Create new account
Product Docs
Matrix Top Plate RF Interfaces
Product Docs
SSMP Connector Installation

Minimize how often the cable is bent, it should be formed once and left in place before being used in a Calibrated path.

Must be used with a SSMP captured launch Block. RIK0321A Block, 2-50 GHz RF



Use the following GPPO Male to SMA Adapter For Calibration
